Product Parameters
16-34m Diesel Telescopic Boom Lifts Specifications
| Model |
ETB16J |
ETB20J |
ETB22J |
ETB24J |
ETB29J |
ETB30J |
ETB34J |
| Max. Working Height(m) | 16 | 20 | 21.9 | 23.7 | 28.7 | 30 | 34 |
| Max. Platform Height(m) | 14 | 18 | 19.9 | 21.7 | 26.7 | 28 | 32 |
| Max. Lift Capacity(kg) | 230 | 480 | 300 | 480 | 480 | 480 | 480 |
| Max. Horizontal Outreach(m) | 12.6 | 15 | 13.7 | 15.8 | 18.5 | 20.6 | 20.6 |
| Stowed Length(m) | 8.55 | 9.07 | 10.06 | 9.1 | 10.76 | 12.79 | 12.6 |
| Gradeability | 45% | 45% | 45% | 45% | 45% | 45% | 45% |
| Weight(kg) | 7500 | 9500 | 9400 | 10400 | 12600 | 16800 | 18500 |
40-63m Diesel Telescopic Boom Lifts Specifications
| Model |
ETB40J |
ETB48J |
ETB58J |
ETB63J |
| Max. Working Height(m) | 40.4 | 48 | 58 | 63 |
| Max. Platform Height(m) | 38.4 | 46 | 56 | 61 |
| Max. Lift Capacity(kg) | 480 | 480 | 480 | 480 |
| Max. Horizontal Outreach(m) | 24 | 23.6 | 26 | 26 |
| Engine Power(kw) | ≈54kw | ≈54kw | ≈54kw | ≈74kw |
| Weight(kg) | 21800 | 23110 | 27500 | 28500 |
Frequently Asked Questions
What is the maximum working height of these boom lifts?
Our series ranges from 16 meters to a maximum of 63 meters working height, catering to various aerial work requirements.
What type of terrain are these lifts suitable for?
The 4X4 drive system and high gradeability (up to 45%) make these telescopic boom lifts ideal for rough terrain and challenging outdoor workshop environments.
Are the lift mechanisms explosion-proof?
Yes, these units feature explosion-proof characteristics, making them suitable for specialized industrial applications where safety is paramount.
What power sources are used for the hydraulic system?
These lifts are powered by high-performance diesel engines (ranging from 36kw to 74kw depending on the model) to drive the hydraulic telescoping mechanisms.
Do these products come with international certifications?
Yes, all our hydraulic platform lifts are CE certified, ensuring they meet rigorous international safety and quality standards.
Can the platform size be customized?
Standard platform sizes range up to 2.44×0.91m. For specific project requirements, please consult with our technical team regarding configuration options.
